Series 5 Depositor

Enquiry

Description

Our Series 5 depositor is predominantly supplied to medium - large scale food producers using conveyors, rotary pot machines or VFFS, but also available with foot pedal control. This high quality volumetric depositor provides damage free depositing of hot or cold liquid, semi-liquid and suspended solid products, and accurately fills most types of container.


Features Include

Semi-automatic with foot pedal control
Fully automatic for use with a conveyor
Choice of piston & barrel size
Fixed position cut-off valve or hand held with flexible hose
40 litre hopper or
direct feed from a product tank outlet
Mobile frame with lockable castors
316 stainless steel in all product contact areas
Simple to operate, hygienic & easy to clean
Requires compressed air supply
12 months warranty
Full after-sales support


Piston & Barrel Sizes

Standard Range

1000 (1.5) 10ml - 170ml
1000 (2.285) 25ml - 400ml
1000 (2.8) 50ml - 600ml
1000 (4.0) 125ml - 1200ml

Maxi Range

1000 (5.125) 200ml - 2500ml
1000 (5.125s) 200ml - 3300ml
1000 (6.5) 500ml - 5000ml


Suitable Food Products

Jam, marmalade, chutney, pickles, relish, honey, peanut butter, condiments, sauces, deli fillers, dips, dressings and marinades, smoothies, soup, ready meals, coleslaw, pate, quiche, sandwich and pie fillings, dairy, bakery and seafood products, cake, pudding and dessert ingredients.


Suitable Non-Food Products

Hand Sanitiser, Cleaning Products, Medical Gels, Cosmetics, Adhesive, Automotive Products, Membranes, Surface Treatments, Resin, Industrial Lubricants & Fillers, Latex, Liquid Fish Bait, Pet Food, Suet Bird Feed, Resin, Saline Solution, Paint, Varnish, Screen Wash, Sealant, Toiletries, Wax.
